TB7100 Installation and Operation Manual Preparation for Operation 105
© Tait Electronics Limited December 2005
7.8 Programmable Features
The programmable features are applied to the transmitter and receiver
modules by using the TB7100 programming application.
7.8.1 Connecting to the PC
1. Plug the TPA-SV-006 or T2000-A19 programming lead into the
RS-232 serial port on a PC.
Note A USB-to-RS-232 adaptor can be used if the PC does not have a
built in serial port.
2. Connect the TMAA20-04 adaptor cable (RJ12 socket to RJ45 plug)
to the RJ12 plug on the TPA-SV-006 or T2000-A19 programming
lead.
3. Plug the RJ45 plug on the TMAA20-04 adaptor cable into the
PROG/MIC connector located on the front panel of the base station.
Select whether the TB7100 programming application communicates with
the transmitter or receiver module by using the receiver/transmitter
programming switch located on the user interface next to the
PROG/MIC
connector.
7.8.2 TB7100 Programming Application
The TB7100 programming application allows the configuration parameters
of receiver or transmitter to be read out of a module, edited and written back
into the module. It is also possible the save the data files, so if a module ever
needs to be replaced, the previously saved data file can be programmed into
the new module. The model toolbar, indicates whether the data file is for a
receiver or transmitter module.
Appearance The TB7100 programming application has been optimised for mouse
navigation. Most features can be easily enabled and configured using a check
box or drop down list and the frequencies for each channel are simply typed
into a table.
