7.12.1 Link Settings
Remove the cover as detailed in “Removing the Base Station and Opening
the Tray” on page 54 and set the jumper positions on the system interface
to match the table below. Replace the cover as detailed in “Final
Reassembly” on page 63. Refer to Figure 7.11 on page 115 for the link
location.
The potentiometers for the tone on idle adjustments shown in the table
below can be found on the system interface module. Refer to Figure 7.11
on page 115 for the potentiometer location.
Table 7.10 Ton on idle (TOI)—link settings
LINK Name Pins Position Function Comments
W401 TOI 9V Enable 2 Fitted
Not fitted
Tone on Idle enable
Tone on Idle disable
Default is fitted
W402 TOI 4.5V Enable 2 Fitted
Not fitted
Tone on Idle oscillator
enable
Tone on Idle oscillator
disable
Default is fitted
Potentiometer Function
RV400 Frequency adjust
RV401 level adjust
