TB7100 Installation and Operation Manual Preparation for Operation 109
© Tait Electronics Limited December 2005
Receiver User-
defined Settings
The user-defined settings for the receiver are shown below. The cells in grey
denote that the value should stay as detailed because of other constraining
settings.
Form Tab Item Name Value Range Recommended
Data General Transparent Mode
Enabled
Enabled / Disabled Enabled
Data General THSD_Modem_
Enabled
Enabled / Disabled Enabled
Data Serial Communications FFSK_Transparent_
Mode_Baudrate
1200, 2400, 4800, 9600,
14400, 19200, 28800
19200
Data Serial Communications THSD_Transparent_
Mode_Baudrate
1200, 2400, 4800, 9600,
14400, 19200, 28800
19200
Basic Settings Basic Network Settings Squelch Detect Type Noise level, Signal strength Noise Level
Basic Settings Sub Audible Signalling Invert Rx DCS Enabled, Disabled Disabled
Channels Detailed RX_Frequency 000.000000…
999.999999
000.000000
Channels Detailed RX Sig CTCSS tone OR DCS tone none
Channels Detailed Network 1…4 1
Channels Detailed Bandwidth 12.5, 20, 25 12.5
Channels Detailed Squelch country, city, hard city
Channels Detailed Use_Channel_For_
Data
Enabled, Disabled Disabled
Key Settings Key 1 Key Action see Key Action type none
Key Settings Key 2 Key Action see Key Action type none
Key Settings Key 3 Key Action see Key Action type none
Key Settings Key 4 Key Action see Key Action type none
UI
Preferences
User Interface Backlight Mode off, activity, continuous off
UI
Preferences
User Interface Backlight Duration 0…15 5
PTT MIC PTT PTT Transmission Type none, voice, data none
