Tait TB7100 Installation And Operation Manual

110 Preparation for Operation TB7100 Installation and Operation Manual
© Tait Electronics Limited December 2005
Transmitter User-
defined Settings
The user-defined settings for the transmitter are shown below. The cells in
grey denote that the value should stay as detailed because of other
constraining settings
Form Tab Item Name Value Range Tx
Data General Transparent Mode
Enabled
Enabled / Disabled Enabled
Data General THSD_Modem_
Enabled
Enabled / Disabled Enabled
Data Serial Communications FFSK_Transparent_
Mode_Baudrate
1200, 2400, 4800, 9600,
14400, 19200, 28800
19200
Data Serial Communications THSD_Transparent_
Mode_Baudrate
1200, 2400, 4800, 9600,
14400, 19200, 28800
19200
Basic Settings Basic Network Settings TX Timer Duration 0…250 0
Basic Settings Basic Network Settings TX Lockout Duration 0…250 0
Basic Settings Sub Audible Signalling CTCSS Lead Out Delay 0…1000 0
Basic Settings Sub Audible Signalling Invert Tx DCS Enabled, Disabled Disabled
Basic Settings Sub Audible Signalling DCS Lead Out Delay 0…1000 0
Channels Detailed TX_Frequency 000.000000…
999.999999
See Note 1
Channels Detailed TX Sig CTCSS tone OR DCS tone none
Channels Detailed Power off, very low, low,
medium, high
high
Channels Detailed Network 1…4 1
Channels Detailed Bandwidth 12.5, 20, 25 12.5
Channels Detailed Use_Channel_For_
Data
Enabled, Disabled Disabled
Key Settings Key 1 Key Action see Key Action type none
Key Settings Key 2 Key Action see Key Action type none
Key Settings Key 3 Key Action see Key Action type none
Key Settings Key 4 Key Action see Key Action type none
UI
Preferences
User Interface Backlight Mode off, activity, continuous off
UI
Preferences
User Interface Backlight Duration 0…15 5
PTT MIC PTT PTT Transmission Type none, voice, data Voice
PTT External PTT 1 PTT Transmission Type none, voice, data Voice
