114 Preparation for Operation TB7100 Installation and Operation Manual
© Tait Electronics Limited December 2005
Digital Input Line Actions
No Action Preset Channel
Toggle Stand-by Mode Mute External Audio Input
Power Sense (Ignition) Mute Audio Output Path
Enter Emergency Mode Unmute Audio Output Path
Send Channel Preset Call Send Mic Audio To Spkr
Send Network Preset Call 1 Force Audio PA On
External PTT 1 and 2
Force Audio PA Off
Inhibit PTT Simulate F1 to F4 Key
Toggle Tx RF Inhibit Toggle F1 to F4 Key LED
Decrement Channel Toggle Alarm Mode
Increment Channel Activate THSD Modem
Home Channel RTS Control (DCE)
BCD Pin 0 to 4
Digital Output Line Actions
No Action Signalling Audio Mute Status
Busy Status SIBT Received
Radio Transmission Status Monitor Status
Channel Lock Status Hookswitch Status
Reflect PTT Status
Call Setup Status
External Alert 1 and 2 Control Status Rx (Line 1 to 3)
Public Address Status Radio Stunned
Serial Data Tx In Progress F1 to F4 Key Status
Reflect PTT Inhibit Status FFSK Data Received Status
Reflect THSD Modem Status CTS Control (DCE)
