68 Connections TB7100 Installation and Operation Manual
© Tait Electronics Limited December 2005
RF Connections
(R
X and TX/ANT)
The RF input to the base station is via the RX connector (N-type) on the
rear panel of the base station. The RF output is via the T
X/ANT connector
(N-type) on the rear panel of the base station.
The RF connector is an N-type connector with an impedance of 50Ω.
Important The maximum RF input level is +27dBm. Higher levels
may damage the radio.
Pin Signal Name Signal Type Notes
1 RF RF analog
2 GND RF ground
B
C
rear view
To Next Page
