264 Transmitter Fault Finding (50W/40W Radios) TM9100 Service Manual
© Tait Electronics Limited August 2005
Figure 11.8 PA circuitry under the
PAF TOP can and part of the directional coupler under the DIRC TOP
can (B1 band)
B1 BAND
C348
C349
C350
D301
Q309
Q310
TEST PAD
MOUNTING POINT FOR
TEST CAPACITOR
TEMPERATURE SENSOR
