3-49
Fig. 3.162
⑥ After adjusting the engagement of the gears,
tighten the bolts securing the cap nut and
bearing cage.
Cap nut tightening torque:
217.7 to 325.6 N-m
{2220 to 3320 kgf-cm}
[161 to 240 ft-lbs]
Note: Apply LOCTITE #270 on the threaded
part.
Install the adjustment nut stopper and split pin
and then pass the wire.
Note: Apply LOCTITE #270 on the threaded
part.
