2-22
Fig. 2.63
Fig. 2.62
Fig. 2.61
2.6 RADIATOR
■ REMOVAL
① Remove the radiator cover (1).
② Rem ove the counterweight. (S ee “2.4
COUNTERWEIGHT.”)
③ Drain the coolant.
④ Remove the radiator hoses (1).
For an automatic transmission truck, remove
the oil cooler hose as well.
Tag all hoses for proper reinstallation.
⑤ Remove the hose (1) leading from the radiator
cap to the reserve tank.
