TCM FD35C9 - 2.1.4 Battery Removal and Reinstallation Procedures

2-4
Fig. 2.13
Fig. 2.15
Fig. 2.14
2.1.4 BATTERY
■ REMOVAL (diesel trucks)
① Disconnect the negative (-) battery cable
(3) from the negative (-) terminal (2) of the
battery 2 (1).
Make sure to disconnect the negative (-)
battery cable rst.
② Disconnect the positive (+) battery cable
(3) from the positive (+) terminal (2) of the
battery 1 (1).
③ Remove the battery cable (3) from the battery
1’s negative (-) terminal (1) and the battery 2’s
positive (+) terminal (2).
