3-63
Fig. 3.205
Fig. 3.207
Fig. 3.206
■REASSEMBLING INPUT SHAFT
① Install the needle bearings (2) and spacer (3)
into the counter gear (1).
② Install the thrust washer (1) and counter gear
assembly (2) onto the input shaft.
③ Install the thrust washer and press-fit the
bearing (1) onto the input shaft. Then install
the snap ring (2).
④ Note that the bearing at the counter gear side
will be installed when reassembling the clutch
housing.
To Next Page
