2-38
⑮ Remove the battery. (See “2.1.4 BATTERY.”)
⑯ Remove each wiring from the engine.
・Starter wiring
・Alternator wiring
・Oil pressure switch wiring
・Temperature sender wiring
STARTER WIRING STARTER WIRING
ALTERNATOR WIRING
ALTERNATOR WIRING
OIL PRESSURE SWITCH WIRING
OIL PRESSURE SWITCH WIRING
TEMPERATURE
SENDER WIRING
TEMPERATURE
SENDER WIRING
To Next Page
