2-43
Fig. 2.116
Fig. 2.118
Fig. 2.117
③ Install the axle support caps (1) using the
bolts (2) and washers (3).
175 N-m {17.8 kgf-m} [129.1 lbf-ft]
Apply LOCTITE #572.
<For an automatic transmission truck>
④ C o n n e c t t he w i r e h a r ne s s ( 2 ) t o t h e
transmission solenoid valve (1).
⑤ Connect the oil cooler hoses (1) to the
transmission case (2).
To Next Page
