MultiLevel Instruction Manual Quick Start
3
Discharge screen – pre-selection
Operation:
The volume pre-selection query can now
be used to modify the default volume by
entering a new value using the number
keys <1>...<0>. The new value must be
greater than the minimum discharge
volume. If this is not the case, the
discharge is uncalibrated.
Use the <Enter> key to accept the value.
Alternatively, press <F3> to cancel the
process and return to the compartment
selection screen.
This step can be repeated for all the compartments.
Once the default values have been entered, the following screen appears:
Discharge screen – Calming
MultiLevel now waits until any liquid
movements have evened out in order to
take a correct measurement.
This is shown on the display as 'Calming'.
~
Non-calmed values: Next to the fuel level
and compartment volume
Discharge screen – Start
This example shows the discharge screen:
• The discharged volume for the compartments to be
discharged is displayed.
• Detailed information on the first compartment is also
displayed.
