3132136 – Correction
between the display on the MultiLevel and bell prover is determined during
measurements in the bell prover.
correction volume of the inclination table and not the residual volume!
target
= volume in the bell prover
V
actual
= MultiLevel display
K
old
= K-factor used to determine V
actual
.
V
target
x K
old
new
= ----------------
V
actual
ATTENTION:
Observe compensation, i.e. compare only V
T
or only V
0
!
3132137 – Preliminary Switch-O
In the case of unfavourably shaped measuring compartments with large
residual volumes that can no longer be measured by the level measuring
serves as an instruction to the driver to check whether there is enough
room in the storage tank for the entire residual volume. If this is not the
case, a printout of the partial volume already measured can be generated
and the remaining product metered out into another tank.
mm
before the residual volume discharge. (With a standard setting, the value should
be > 45 mm.)
0
3132138 – Inclination Stop
If the inclination of the vehicle is not within the permitted calibration limits when
the wet leg sensor runs dry, an uncalibrated measurement takes place, since it
is not certain whether residual quantities have remained in the compartment.
A preliminary check can be activated via the inclination stop. If the inclination
is not adhered to when the level falls below the set height, the delivery
is STOPPED and a corresponding error message is generated. The operator
a calibrated delivery.
mm
0 means that the inclination stop is deactivated
9999 means check before starting delivery
MultiLevel Instruction Manual MENU structure
