STEP 600 XTPRO: Service & Maintenance Manual - rev. 1.1
Page 2.3
2.5.1. CONNECTORS
• CPU board
Name type of connector connection
CN1 AMP MATE-N-LOCK 12 -pin F. to alternator interface board
CN2 Flat 10-pin to RJ45-RS232 board
CN4 AMP MODU II 6-pin M. to cardio receiver
CN7 AMP MODU II 4-pin M. to HS interface board
• RJ45-RS232 board
Name type of connector connection
CN1 Male panel connector DB9 to TGS reader
CN2 Panel RJ45 to Cardio Theater
CN3 Female panel connector DB9 to external device (not used)
CN4 Flat 10-pin to CPU board
• Power supply
Name type of connector connection
CN1 PANDUIT 6-pin to mains power supply
CN2 PANDUIT 7-pin to alternator interface board
FG Faston to ground
• Alternator interface board
Name type of connector connection
CN1 AMP MATE-N-LOCK 15-pin F. to CPU board
CN2 AMP MATE-N-LOCK 6-pin F. to alternator
CN3 AMP MODU I 4-pin M. to power supply
• HS interface board
Name type of connector connection
HD2 Molex 3-pin to left hand sensor
HD3 Molex 3-pin to right hand sensor
HD4 Molex 3-pin to CPU board
