9. CONFIGURING THE MACHINE
9.1. MACHINE HW CONFIGURATION
The HW configuration of the machine is set using the 2 banks of dip-switches on the back of the
CPU board, according to the tables below:
9.1.1. MACHINE NO. CONFIGURATION
Using the bank of 4 dip-switches on the back of the CPU board, it is possible to set the machine
number as illustrated below:
Right hand bank
Dip-switch
1 2 3 4
Number
ON OFF OFF ON 1 – MASTER
OFF ON OFF OFF 2
ON ON OFF OFF 3
OFF OFF ON OFF 4
ON OFF ON OFF 5
To be enabled for printing, the machine must be configured with all dip-switches in ON
position.
9.1.2. ALTERNATOR CONFIGURATION
This procedure is applicable starting from SW version 7.0.X .
Using dip-switch No. 1 of the 2-switch bank on the back of the CPU board, it is possible to set the
type of alternator that is fitted on the machine, as indicated below:
Left-hand bank
Dip-switch
1
Alternator
ON
EFEL
REAL
MAGNETI MARELLI
OFF PESTOLITE
9.1.3. MICROSWITCH CONFIGURATION
This procedure is applicable starting from SW version 7.0.X .
Using dip-switch No. 2 of the 2-switch bank on the back of the CPU board, it is possible to
configure the method of setting the stepping mode:
