UNICA EVOLUTION: Service & Maintenance Manual - rev. 1.1
Page 3.2
3.3. MOVING
Once the machine has been assembled, it can be moved over short distances using the two wheels
supplied with the machine.
Figure 3.3-1
1. Screw the two wheels of Figure 3.3-1 into
the special holes on the sides of the weight
stack column using a 17 mm Box wrench.
Figure 3.3-2
2. Insert the ring provided a into the footrest
and the bottom hook into the Leg Extension
lever as shown in the figures Figure 3.3-2.
Continued on following page →
