10.5. SERVICE: PERIPHERALS CHECK PANEL
To access this procedure, select the SERVICE item from the main configuration menu and enter the
password “2501” which protects against unauthorized access. Use the two center keys to enter the
first password digit, then press OK; proceed in the same way for the other digits. After pressing
OK to confirm the last digit, a new menu appears:
SERVICE
MACHINE CONFIGURATION
PERIPHERALS CHECK PANEL
CHECK/SET COUNTERS
Scroll down with the center keys until the PERIPHERALS CHECK PANEL item illuminates, then
press OK. The display shows:
VISUALISE DATA
FRAME 127: 56: 3:240 412
DISL 412 DISM 0 2.5 KG
PINOUT N LOAD DW Y AW Y
This view is used for monitoring the status of the sensors and the serial communications between
the FPGA board and the CPU board (continuous transmission of 4 bytes from the FPGA board see
paragraph Errore. L'origine riferimento non è stata trovata.). The display shows:
• 1
st
LINE: shows the value of the 4 bytes of the communication protocol between the 2 boards,
in decimal format, separated by “:”. The last number is the selector pin position in
mm, obtained from the values of the 2
nd
and 3
rd
bytes;
• 2
nd
LINE: shows the following 3 values:
- DISL: the selector pin position in mm, acquired during the last weight selection
before running the configuration procedure;
- DISM: the relative displacement of the selector pin from its original position, in
mm, acquired before running the configuration procedure;
- last selected weight before running the configuration procedure.
• 3
rd
LINE: readout of the machine status:
- PINOUT: with the encoder currently used this value is always N;
- LOAD DW: shows the status of the weight stack: Y if the weight stack is in the
rest position, and N if the weight stack is raised. In other words, this parameter
monitors the state of the weight stack sensor;
