UNICA EVOLUTION: Service & Maintenance Manual - rev. 1.1
Page 6.4
6.3. WEIGHT STACK
If it is necessary to disassemble the weight stack from the machine, proceed as follows:
1. Overturn the machine on its rear side;
2. Separate the weight stack column from the rest of the frame;
3. Back off the guide rod fixing screws and the bolts securing the weight stack to the base of the
column;
4. Remove the guide rods from the upper part of the weight stack column and pull out the plates
which are now free to come out.
The detailed procedure for disassembling the weight stack column is described in the
installation CD Rom.
