ENGLISH
User’s manual 48 UPS EVO DSP PLUS Modular
Table 6-1: DIP Switch Setting and Module Address
Module Address
DIP SWITCH
Module Address
DIP SWITCH
0
1 2 3
1
1 2 3
2
1 2 3
3
1 2 3
4
1 2 3
5
1 2 3
6
1 2 3
7
1 2 3
Table 6.2: Module ID Assignment
SW1 - SW2
Module Address
Module ID
SW1 - SW2
Module Address
Module ID
SW1 SW2
0
0
SW1 SW2
0
9
1
1
1
10
2
2
2
11
3
3
3
12
4
4
4
13
5
5
5
14
6
6
6
15
7
7
7
16
SW1 SW2
0
18
SW1 SW2
0
27
1
19
1
28
2
20
2
29
3
21
3
30
4
22
4
31
5
23
5
32
6
24
6
33
7
25
7
34
