12 Technical Characteristics
UPS EVO DSP PLUS Modular
Power
20 ~ 300 KVA
Nominal Active Power
20 ~ 300 KW
Power Factor
1
Technology
On-Line Double Conversion Transformerless (VFI-SS-111)
INPUT
Rated Power
20 ~ 300 KVA
Phases
3 Phases four-wire, with Neutral reference to the Bypass Neutral
Nominal Voltage (Phase-Phase)
380 / 400 / 415 Vac (selectable)
Nominal Voltage (Phase-Neutral)
220 / 230 / 240 Vac (selectable)
Voltage Range
Line Mode
Full Load
305V ~ 478V (176V ~ 276V Phase-Phase)
70% Load (De-rating)
208V ~ 478V (120V ~ 276V Phase-Phase)
Nominal Frequency
50/60 Hz (Auto-selectable)
Frequency Range (Line mode)
40Hz ~ 70Hz
Synchronized Range
+/- 1Hz, +/- 2Hz, +/- 4Hz (default: 4Hz) (selectable)
Total Harmonic Distortion Input (THDi)
< 3% (at 100% Load with Linear Load)
Input Power Factor
≥ 0.99 (at 100% Load)
INVERTER OUTPUT
Rated Power
20 ~ 300 KVA
Phases
3 Phases four-wire, with Neutral reference to the Bypass Neutral
Nominal Voltage (Phase-Phase)
380 / 400 / 415 Vac (selectable)
Nominal Voltage (Phase-Neutral)
220 / 230 / 240 Vac (selectable)
Voltage Regulation
≤ 1% Typical (Balanced Load); ≤ 2% Typical (Unbalanced Load)
Inverter Waveform
True Sinewave
Nominal Frequency
50/60 Hz (selectable)
Frequency Range (Synchronized Range)
40Hz ~ 70Hz
Frequency Range (Battery mode)
(50 Hz ± 0.1%) or (60 Hz ± 0.1%)
Total Harmonic Distortion (THD)
≤ 2% (100% Linear Load); ≤ 4% (100% Non-Linear Load)
Crest Factor
3:1 max
Overload (Line mode)
1 hour for 105 ~110%, 10 mins for 111~125%, 1 min for 126~150%, 200ms for >150%
Overload (Battery mode)
1 hour for 105 ~110%, 10 mins for 111~125%, 1 min for 126~150%, 200ms for >150%
Transfer Time
(Line <--> Battery)
0 ms
(Battery <--> Bypass)
0 ms
