Checks and Adjustments
5–2
1720/1721
PAL TEKTRONIX 1411 with Option AA and Option AB (modified SPG12
and TSG11) and TSG13.
PAL-M TEKTRONIX 1412 with Option AA and Option AB (modified
SPG22 and TSG21) and TSG23.
The 1410, 1411, and 1412 Option AA are mainframes with modified SPG2,
12, and 22 Sync Generators with the added features of: Variable Subcarrier
Frequency (±20 Hz, ±50 Hz for the 1410; ±5 Hz, ±10 Hz for the 1411 and
1412), Variable Burst amplitude, Variable Sync amplitude, and SCH unlock.
NOTE.
The 1410 Series generators with standard SPG and TSG modules can be used,
but this will not allow all checks and adjustments to be made.
The 1410, 1411, and 1412 Option AB are mainframes with modified TSG7,
11, and 21 Color Bar Generators that more accurately control output
amplitudes of the standard 75% amplitude bars.
The Signal Generator mainframes can be ordered with one or both options
(AA and AB).
The TSG3, 13, and 23 are Modulated Staircase Generators with variable
APL.
3. Leveled Sine Wave Generator, 50 kHz to 10 MHz
For example: A TEKTRONIX SG503 Leveled Sine Wave Generator
installed in a TEKTRONIX TM500 Series Power Module. Flatness ±1%,
250 kHz to 50 MHz. The flatness can be calibrated (a chart made of
variations) with the TEKTRONIX Peak-to-Peak Detector (015-0408-00).
4. Function Generator, –10 V pulse at 1 kHz
For example: A TEKTRONIX FG501A Function Generator installed in a
TEKTRONIX TM500 Series Power Supply Module.
5. Voltmeter, 0 to >100 Vdc; accuracy, ±0.1%
For example: A TEKTRONIX DM504A in a TM500 Series Power Module.
6. Power Module (required for Items 3, 4, and 5)
For powering and housing TEKTRONIX DM504A, SG503A, FG501A.
