Tektronix 1720 User Manual

Replaceable Mechanical Parts
10–4
1720/1721
Replaceable Mechanical Parts
Fig. &
index
no.
Tektronix
part no.
Serial number
Effective Dscont
Qt
y Name & description
Mfr.
code
Mfr. part no.
1–1 426–2102–00 1 FRAME,CRT:BEZEL TK1151 ORDER BY DESC
*MOUNTING PARTS*
–2 211–0690–02 2 SCREW,MACHINE:6–32 X 0.875,PNH,SST 93907 B20–70430
*END MOUNTING PARTS*
–3 333–3306–00 1 PANEL,FRONT:1720 22670 ORDER BY DESC
–4 378–0258–00 1 FLTR,CONTRASTIN:GRAY,POLYCARBONATE 80009 378025800
–5 333–3302–01 B050000 B059999 1 PANEL,FRONT:MAIN 80009 333330201
333–3302–02 B060000 1 PANEL,FRONT:MAIN FRONT PANEL,1720 80009 333–3302–02
(1720 ONLY)
333–3303–01 B050000 B059999 1 PANEL,FRONT:1721 80009 333330301
333–3303–02 B060000 1 PANEL,FRONT:FRONT PANEL,1721 80009 333–3303–02
(1721/1721PM/1721PN ONLY)
*MOUNTING PARTS*
–6 211–0721–00 2 SCREW,MACH:6–32 X 0.375,PNH,STL,CDPL,T–15 TORX DR 0KB01 ORDER BY DESC
*END MOUNTING PARTS*
–7 366–2068–00 1 KNOB:GRAY,0.46 ID X 0.588 OD X 0.6 H 7X318 ORDER BY DESC
–8 ––––––––––– 1 PHASE SHIFTER:
(SEE A4 REPL)
*MOUNTING PARTS*
–9 210–0580–00 1 NUT,PLAIN,HEX:0.312–32 X 0.375,BRS NP 73743 24030–101
–10 210–0519–00 1 WASHER,FLAT:0.312 ID X 0.44 OD X 0.016,AL 12327 ORDER BY DESC
–11 210–0048–00 1 WASHER,LOCK:0.32 ID INTL,0.015 THK,STL CD PL 09772 ORDER BY DESC
–12 210–1025–00 2 WASHER,FLAT:0.312 ID X 0.469 OD X 0.031,BRS 12327 ORDER BY DESC
*END MOUNTING PARTS*
–13 ––––––––––– 1 CIRCUIT BD ASSY:FRONT PNL
(SEE A2 REPL)
*MOUNTING PARTS*
–14 211–0721–00 4 SCREW,MACH:6–32 X 0.375,PNH,STL,CDPL,T–15 TORX DR 0KB01 ORDER BY DESC
*END MOUNTING PARTS*
–15 426–2101–01 B050000 B059999 1 FRAME SECT,CAB.:FRONT TK1151 ORDER BY DESC
426–2101–04 B060000 1 FRAME SECTION:FRAME SECTION,CABINET,FRONT 7X318 1350
*MOUNTING PARTS*
–16 211–0721–00 3 SCREW,MACH:6–32 X 0.375,PNH,STL,CDPL,T–15 TORX DR 0KB01 ORDER BY DESC
*END MOUNTING PARTS*
–17 ––––––––––– 1 SWITCH,PUSH:0.4A,125VAC,W/SOLDER LUG,BUTTONW/
YELLOW INDICATOR
(SEE S1 REPL)
*MOUNTING PARTS*
–18 210–0405–00 2 NUT,PLAIN,HEX:2–56 X 0.188,BRS CD PL 73743 12157–50
–19 211–0100–00 2 SCREW,MACHINE:2–56 X 0.750,PNH,STL TK0435 ORDER BY DESC
*END MOUNTING PARTS*
–20 ––––––––––– 1 CIRCUIT BD ASSY:MAIN
(SEE A3 REPL)
*MOUNTING PARTS*
–21 211–0721–00 8 SCREW,MACH:6–32 X 0.375,PNH,STL,CDPL,T–15 TORX DR 0KB01 ORDER BY DESC
*END MOUNTING PARTS*
–22 196–3146–00 6 CA ASSY,SP:FLAT FLEX,;FLX,27 AWG,1.0 L,PCB,TERM,STR
BOTH ENDS
TK0196 FSN–1A,P OR K
–23 ––––––––––– 1 CIRCUIT BD ASSY:GRATICULE LIGHT
(SEE A3A1 REPL)
