1: Introduction Models 2450-EC, 2460-EC, and 2461-EC Potentiostats And Galvanostats
1-4 077110402/November 2016
Copy a script to the instrument
Your SMU is shipped with all test applications and supporting scripts loaded into memory.
If you accidentally delete a test application or a supporting script (EC_Framework.tsp or
EC_Images.tsp), you can copy the files from the flash drive to your instrument.
If you are upgrading your SMU with the EC-UPGRADE kit, you can run the test applications from the
flash drive or copy the files from the flash drive to the instrument. If you choose to copy the
applications, you must also copy the support files (EC_Framework.tsp and EC_Images.tsp) to
your SMU.
To copy a script to the SMU:
1. Insert the USB flash drive into the USB port on the front panel.
2. Press the MENU key.
3. Under Scripts, select Manage. The Manage Scripts menu opens. Your list of Internal Scripts may
appear different.
Figure 1: Manage Scripts menu
4. In the USB Scripts list, select the test script you want to copy to the SMU. For this example, you
will copy the Cyclic Voltammetry test script.
Figure 2: Selecting the test script to be copied
