-, 2460-, & 2461-EC Potentiostats And Galvanostats User's Manual Section 5:
Current Pulse and Square Wave
077110402/November 2016 5-3
Run the Current Pulse and Square Wave test application
To run the test application:
1. Press the HOME key.
2. Select the active script indicator at the top of your home screen. If there is no script activity, the
indicator displays "No Script."
Figure 84: Active script indicator
3. Select the preloaded Current Pulse and Square Wave test script (potentiostats and galvanostats
only) or connect the supplied USB drive to your SMU instrument to locate the included Current
Pulse and Square Wave test. If you connect the USB drive, scripts on the drive are displayed with
usb1/ before the script file name.
Figure 85: Selecting the Current Pulse and Square Wave test application
4. Select CurrentPulseAndSquareWave. The test application begins to run immediately and the
Current Pulse and Square Wave Home screen is displayed.
Figure 86: Current Pulse and Square Wave test Home screen
