Tektronix KEITHLEY 2450-EC - Save or Load the Test Parameter Data

Models 2450
-, 2460-, & 2461-EC Potentiostats And Galvanostats User's Manual Section 5:
Current Pulse and Square Wave
077110402/November 2016 5-9
Save or load the test parameter data
You can save your test parameters to the front-panel flash drive at any time. Up to five test parameter
configurations can be stored.
To save the test parameters:
1. From the Menu screen, select Save Settings. Note that your Menu screen options are different
depending on the test you are running.
If you have saved a settings file previously with the same File Selection number, you will be
prompted to overwrite it.
Figure 96: Selecting Save Settings
2. You are notified when the save is complete. Select OK to clear the prompt.
Figure 97: Successful file save
