-EC, 2460-EC, and 2461-EC Potentiostats And Galvanostats User's Manual Section 3:
077110402/November 2016 3-7
To load saved test parameters:
Test parameters can only be loaded to the same instrument model on which they were created and
saved. For example, you cannot load test parameter settings created with a 2450-EC to a 2460-EC.
1. From the Menu screen, select Load Settings.
2. Select a file by choosing File Selection and then a file number.
Figure 55: Choosing a file to load
3. Select Load Settings. You are notified when the load completes.
4. Select OK to clear the prompt.
Run the test and view the graph
To start the experiment and view the graph or data:
1. Press the HOME key.
2. Select Start Test. The output turns on and the display automatically shows the potential
measurements plotting in real time, along with a progress bar at the bottom of the screen. The
Start Test control also changes to Stop Test for the duration of the test.
The output turns off when the test completes. The following graphic shows the Home screen after the
test finishes. You can return to this Home screen at any time when the test is running by selecting the
Run / Graph option from the Menu screen.
Figure 56: Open Circuit Potential test results graph
