3: Open Circuit Potential Models 2450-EC, 2460-EC, and 2461-EC Potentiostats And Galvanostats
3-4 077110402/November 2016
Adjust the Measure Settings
When you run the test application, you must define the parameters for the open circuit potential
measurements. These parameters are the Potential range, Sample Count, and the Sample Interval.
To select the Potential Range:
1. Press the MENU key, then select Measure Settings.
2. Select Potential Range.
Figure 48: Measure Settings menu, selecting Potential Range
3. Choose a value. Note that the choices are different depending on your galvanostat.
Figure 49: Selecting the Potential Range
Next, specify the number of Open Circuit Potential measurements to make. This is called the Sample
Count. You can set the Sample Count from 1 to 100,000.
To set the number of samples:
1. From the Measure Settings screen, select Sample Count.
Figure 50: Measure Settings menu, selecting Sample Count
