Tektronix KEITHLEY 2450-EC - Save or Load the Test Parameter Data

Section
2: Cyclic Voltammetry Models 2450-EC, 2460-EC, and 2461-EC Potentiostats And Galvanostats
User's Manual
2-10 077110402/November 2016
Save or load the test parameter data
You can save your test parameters to the front-panel flash drive at any time. Up to five test parameter
configurations can be stored.
To save the test parameters:
1. From the Menu screen, select Save Settings.
If you have saved a settings file previously with the same File Selection number, you will be
prompted to overwrite it.
Figure 27: Selecting Save Settings
2. Select a file number and then select Save Settings. You are notified when the save is complete,
as shown in the next figure. Select OK to clear the prompt.
Figure 28: Successful file save
