-EC, 2460-EC, and 2461-EC Potentiostats And Galvanostats User's Manual Section 7:
077110402/November 2016 7-5
To define the Number of Steps:
1. Press the MENU key, then select Step Settings.
2. Select Number of Steps.
3. Enter a value, then select OK. The next figure shows three steps defined.
Figure 130: Step Settings menu
Next, you must define the Current and Duration for each step.
To define the Current and Duration:
1. From the Measure Settings menu, select a step Current.
2. Enter step Current value, then select OK.
3. Select a step Duration.
4. Enter a step Duration value, then select OK.
Now, you will define the Measure Settings parameters of Potential Range, Sample Time, and Sample
Interval.
Figure 131: Measure Settings menu
