GPS7 GPS Synchronization and Timecode module remote commands
:SOURce:TIMES
et:NLLOSs:GPO:MDELay
<numeric_value>,<numeric_v alue>,<numeric_value> (HH:MM:SS)
NOTE. This command is not supported by GPS7 modules that do not have a REF
IN connector.
Sets a delay time for the GPI alarm to report a near loss of lock condition
(Genlock on
ly).
:SOURce:TIMESet:NLLOSs:GPO :MDELay?
Returns the delay time for the GPI alarm to report a near loss of lock condition
(Genlock only).
:SOURce:TIMESet:NOGL:GPO:M DELay
<numeric_value>,<numeric_v alue>,<numeric_value> (HH:MM:SS)
NOTE. T
his command is not supported by GPS7 modules that do not have a REF
IN connector.
Sets a delay time for the GPI alarm to report no genlock input.
:SOURce:TIMESet:NOGL:GPO:M DELay?
Returns the delay time for the G PI alarm to report no genlock input.
:SOU
Rce:TIMESet:SWARning:GPO:MDE Lay
<numeric_value>,<numeric_v alue>,<numeric_value> (HH:MM:SS)
Set
the dela y between when a signal warning is detected, and when it is
reported on the GPI output.
:S
OURce:TIMESet:SWARning:GPO: MDELay?
Returns the delay time between when a signal warning is detected, and when
i
t is reported on the GPI output.
:SOURce:GPIo:INPut RESET_COUN T | REACQ_SAT | JAM
Sets the action to take when the input pin on the GPI (General Purpose
Interface) connector is asserted. The choices are: RESET_COUNT - reset
the program time counter back to initial time; REACQ_SAT - trigger the
reacquire satellite position; and JAM - trigger a jam sync.
:SOURce:GPIo:INPut?
Returns the GPI action to be taken when the input pin on the GPI connector is
asserted.
Draft
TG8000 Multiformat Test Signal Generator Programmer Manual 89
