HD3G7 3 Gb/s SDI Video Generator module remote commands
42= Blue-2 Fiel
d
43= Cyan-2 Field
44= Magneta-1 Field
45= Magenta-2 Field
46= Yellow-1 Field
47= Yellow-2 Field
48= Convergence
49= Checkerboard
50= Production Aperture
51= Window
52= Equalizer Test
53= PLL Test
54= SDI Matrix
:OUTPut1:SYNThesizer:CINEm a:PROJector?
Returns the projector test pattern setting.
:OUTPut1:SYNThesizer:STATe GE N|CONV
Sets the synthesizer to generatororconvergencemode.
:OUTPut1:SYNThesizer:STATe ?
Returns the current synthesizer mode.
:OUTPut1:SYNThesizer:SIGNa l
NOTE. The SIGNal and SIGNal? commands do not give full access to the test
patterns available to this module. Use the SIGNAL:COUNT, SIGNAL:LOAD,
and SIGNAL:LIST commands.
COLBAR_100P|COLBAR_75P|CO LBAR_SMPTE|FF_0P|
FF_10P|FF_20P|FF_30P|FF_4 0P|FF_50P|
FF_60P|FF70_P|FF_80P|FF_9 0P|FF_100P|
LIN_5STEP|LIN_10STEP|LIN_ RAMP|LIN_SHALLOW_RAMP|
LIN_GRAD_RAMP|LIN_VRAMP|
MON_RED|MON_75RED|MON_GRE EN|MON_75GREEN|MON_BL
UE|
MON_75BLUE|MON_CONV| PULSE_2 T30|PULSE_2T60|
SDI_EQU|SDI_PLL|SDI_MTX|
ZP_CIRCLE|ZP_DIAG|ZP_HSIN E|ZP_HSWEEP|ZP_VSINE|
ZP_VSWEEP|ZP_1_CUSTOM|ZP_ 2_CUSTOM
Draft
TG8000 Multiformat Test Signal Generator Programmer Manual 115
