Tektronix TG8000

HD3G7 3 Gb/s SDI Video Generator module remote commands
Sets the HD test
signal. Before sending this command, you need to set the
:OUTPut<n>:SYNThesizer:STATe command to GEN. The options are as
follows:
COLBAR_100P 100% Color Bars
COLBAR_75P 75% Color Bars
COLBAR_SMPTE SMPTE RP219 Color Bars
FF_0P
0% Flat Field
FF_10P
10% Flat Field
FF_20P
20% Flat Field
FF_30P
30% Flat Field
FF_40P
40% Flat Field
FF_50P
50% Flat Field
FF_60P
60% Flat Field
FF_70P
70% Flat Field
FF_80P
80% Flat Field
FF_90P
90% Flat Field
FF_100P
100% Flat Field
LIN_5STEP 5 Step Staircase
LIN_10STEP 10 S tep Staircase
LIN_RAMP Ramp
LIN_SHALLOW_RAMP Shallow Ramp
LIN_GRAD_RAMP Gradient Ramp
LIN_VRAMP Valid Ramp
MON_RED 100% Red Field
MON_75RED 75% Red F ield
MON_GREEN 100% Green Field
MON_75GREEN 75% Green Field
MON_BLUE 100% Blue Field
MON_75BLUE 75% Blue Field
MON_CONV Convergence
PULSE_2T30
2T30 Pulse and Bar
PULSE_2T60
2T60 Pulse and Bar
SDI_EQU
Equalizer Test
SDI_PLL
PLL Test
SDI_MTX SDI Matrix
ZP_CIRCLE Circle Zone Plate
ZP_DIAG Diagonal Sine Zone Plate
ZP_HSINE Diagonal Sine Zone Plate
ZP_HSWEEP Horizontal Sine Zone Plate
