HDLG7 HD Dual Link Video Generator module remote commands
:SELect
GBR444_12B|GBR444_ 10B|GBR444A _10B|
YCB444_12B|YCB444_ 10B|YCB444A _10B|
YCB422_12B|YCB422_ 10B|YCB422A _12B|
GBR444_2K|XYZ444_2K
:STANdard
HD1080_60P|HD1080_ 59P|HD1080_ 50P|
HD1080_60I|HD1080_ 59I|HD1080_ 50I|
HD1080_30P|HD1080_ 29P|HD1080_ 25P|
HD1080_24P|HD1080_ 23P|HD1080_ 24SF|
HD1080_23SF|TK1556 _14SF|TK155 6_15SF|
TK1556_17SF|TK1556 _18SF|TK108 0_23SF|
TK1080_24SF|TK1080 _25SF|TK108 0_29SF|
TK1080_30SF|TK1080 _23P|TK1080 _24P|
TK1080_25P|TK1080_ 29P|TK1080_ 30P
:SYNThesi
ze
:CINEma
:COLOr
RGB|PROJ
:GRAD
:HORizontal
<16, 17, 18, ... , 1912,
1913>
:VERTical
<16, 17, 18, ... , 2880>
:PROJector
<0,1,2,... ,46,47>
:CATalog?
:STATe
ON|OFF
:SIGNal COLBAR_100P|COLBAR_75 P|COLBAR_SM PTE|
FF_0P|FF_10P|FF_20 P|FF_30P|FF _40P|
FF_50P|FF_60P|FF_7 0P|FF_80P|F F_90P|
FF_100P|LIN_5STEP| LIN_RAMP|LI N_VRAMP|
MON_RED|MON_75RED| MON_GREEN|
MON_75GREEN|MON_BL UE|MON_75BL UE|
MON_CONV|PULSE_2T3 0|SDI_EQU|S DI_PLL|
SDI_MTX
Command description
:OUTPut1:ALPHa COPY_YG|FF_0P| FF_10P|FF_20P|FF_30P|FF_40P|
FF_50P|FF_60P|FF_70P|FF_80 P|FF_90P|FF_100P|
Sets the a lpha channel signal. The choices are COPY_YG (fills the alpha
channel with Y or G data from the input signal), FF_0P (0% Flat Field),
FF_10P (10% Flat field), FF_20P (20% Flat field), FF_30P (30% Flat field),
FF_40P (40% Flat field), FF_50P (50% Flat field), FF_60P (60% Flat field),
FF_70P (70% Flat field), FF_80P (80% Flat field), FF_90P (90% Flat field),
and FF_100P (100% Flat field).
:OUTPut1:ALPHa?
Returns the current alpha channel signal.
:OUTPut1:CONVert:BLACkwhit e ON|OFF
Draft
TG8000 Multiformat Test Signal Generator Programmer Manual 127
