HDLG7 HD Dual Link Video Generator module remote commands
:OUTPut1:SYNT
hsize:CINEma:GRAD:HORizontal <1 6, 17, 18, ...
,1913>
Sets the start offset of the Horizontal Gradient projector test pattern. You can
set the value from 16 to 1913 in 1 level steps.
:OUTPut1:SYNThsize:CINEma:GRAD:HORizontal?
Returns the current start offset of the Horizontal Gradient projector test
pattern.
:OUTPut1:SYNThsize:CINEma :GRAD:VERTical <16, 17, 18, ... ,
2880>
Sets the start offset of the Vertical Gradient projector test pattern. For the 2048
x 1080 format, you can set the value from 16 to 2880 in 1 level steps. For the
2048 x 1556 format, you can set the value from 16 to 2405 in 1 level steps.
:OUTPut1:SYNThsize:CINEma :GRAD:VERTical?
Returns current start offset of the Vertical Gradient projector test pattern.
:OUTPut1:SYNThesize:CINEm a:PROJector <0, 1, 2, ..., 46, 47>
Sets the projector test pattern. Before sending this command,
set the :OUTPut1:SYNThesize:STATe command to ON and
:OUTPut1:SYNThesize:CINEma:COLOr to PROJ. The possible settings are:
0: Color Bar Patch-1 24: Black to Gray Step-7
1: Color Bar Patch-2 25: Black to Gray Step-8
2: Step B lack-White 26: Black to Gray Step-9
3: Step Black-Dark Gray 27: Black to Gray Step-10
4: Horizontal Gradient
28: Red-1 Field
5: Vertical Gradient
29: Red-2 Field
6: Black Flat Field
30: Green-1 Field
7: White Flat Field
31: Green-2 Field
8: Black to W hite Step-1
32: Blue-1 Field
9: Black to W hite Step-2
33: Blue-2 Field
10: Black to White Step-3 34: Cyan-1 Field
11: Black to White Step-4 35: Cyan-2 Field
12: Black to White Step-5
36: Magenta-1 Field
13: Black to White Step-6
37: Magenta-2 Field
14: Black to White Step-7
38: Yellow-1 Field
15: Black to White Step-8
39: Yellow-2 Field
16: Black to White Step-9 40: GRID
17: Black to White Step-10 41: Checkboard
18: Black to Gray Step-1
42: Aspect Ratio
Draft
130 TG8000 Multiformat Test Signal Generator Programmer Manual
