Tektronix TG8000 Programmer's Manual

HDLG7 HD Dual Link Video Generator module remote commands
:OUTPut1:SAMP
ling:SELect GBR444_12B|GBR444_1 0B|GBR444A_10B|
YCB444_12B|YCB444_10B|YCB4 44A_10B|
YCB422_12B|YCB422_10B|YCB4 22A_12B| GBR444_2K|XYZ444_2K
Sets the sampling structure for the output test signal. The options are as
follows:
GBR444_12B 1080 4:4:4 GBR 12 bits
GBR444_10B 1080 4:4:4 GBR 10 bits
GBR444A_10B 1080 4:4:4 GBR+A 10 bits
YCB444_12B 1080 4:4:4 YCbCr 12 bits
YCB444_10B 1080 4:4:4 YCbCr 10 bits
YCB444A_10B 1080 4:4:4 YCbCr+A 10 bits
YCB422_12B 1080 4:2:2 YCbCr 12 bits
YCB422_10B 1080 4:2:2 YCbCr 10 bits
YCB422A_12B 1080 4:2:2 YCbCr+A 12 bits
GBR444_2K 2K 4:4:4 GBR 12 bits
XYZ444_2K 2K 4:4:4 XYZ 12 bits
The GBR444_2K and XYZ444_2K options are only available when any 2K
format is selected by the :OUTPut1:STANdard command.
:OUTPut1:SAMPling:SELect?
Returns the current sampling structure.
:OUTPut1:STANdard
HD1080_60P|HD1080_59P
|HD1080_50P|HD1080_60I|
HD1080_59I|HD1080_50I|HD10 80_30P|HD1080_29P|
HD1080_25P|HD1080_24P|HD10 80_23P|HD1080_24SF|
HD1080_23SF|TK1556_14SF|TK 1556_15SF|
TK1556_17SF|TK1556_18SF|TK 1080_23SF|
TK1080_24SF|TK1080_25SF|TK 1080_29SF|
TK1080_30SF|TK1080_
23P|TK1080_24P|TK1080_25P|
TK1080_29P|TK1080_30P
Sets the video standard of the output signal. TK1556_xx and TK1080_xx
arguments represent 2K video formats.
:OUTPut1:STANdard?
Returns the current video standard.
:OUTPut1:SYNThesize:CINEma :COLOr RGB|PROJ
Sets the 2K test signal color space. The choices are RGB (Rec.709 Test
pattern) and PROJ (Projector Test Pattern).
:OUTPut1:SYNThsize:CINEma: COLOr?
Returns the current 2K test signal color space.
Draft
TG8000 Multiformat Test Signal Generator Programmer Manual 129
