SDI7 Dual Channel SD/HD/3G SDI Video Generator module remote commands
:STATe?
:VIDeo
:Y
:STATe
<Boolean>
:STATe?
:PB
:STATe
<Boolean>
:STATe?
:PR
:STATe
<Boolean>
:STATe?
Command description
:OUTPut<1|2>:ALPHa COPY_YG|FF _0P|FF_10P|FF_20P|FF_30P|
FF_40P|FF_50P|FF_60P|FF_70 P|FF_80P| FF_90P|FF_100P
Sets the content of the alpha channel, which is p resent in certain 3G-SDI
formats. Select C OPY_YG to fill the alpha channel with the same data values
as the Y or G channel of the current test pattern, or select FF_0P...FF_100P to
select a flat field value from 0% to 100%.
:OUTPut<1|2>:ALPHa?
Returns the current value for alpha channel data for the selected generator
output.
:OUTPut<1|2>:ANC:OUTMode DIS| CONT|SING
Sets the user-defined ancillary data output mode of the selected generator
output. The choices are DIS (disable), CONT (continuous), and SING (single
packet).
:OUTPut<1|2>:ANC:OUTMode?
Returns the output mode setting of the user-defined ancillary data packet for
the selected gener ator output.
:OUTPut<1|2>:ANC:PARIty MAN|A UTO
Sets the parity of the user-defined ancillary data packet for the selected
generator output. The choices are AUTO (automatic calculation) and MAN
(manual setting). When AUTO is chosen, 8-bit values can be specified for
the DID, SDID, DBN, and UDW words and the parity bits will be correctly
encoded. When MAN is chosen, the complete 10-bit value must be specified
for these words.
:OUTPut<1|2>:ANC:PARIty?
Returns the parity setting of the user-defined ancillary data packet.
:OUTPut<1|2>:ANC:LINe <NR1>,< NR1>
Draft
TG8000 Multiformat Test Signal Generator Programmer Manual 153
