SDI7 Dual Channel SD/HD/3G SDI Video Generator module remote commands
YCB422A_12B 4:2:2 YCbCr+A 12 bits
XYZ444 4:4:4 XYZ 12 bi
ts
:OUTPut<1|2>:SAMPling?
Returns the
sampling structure for the specified generator output.
:OUTPut<1|2>:STANdard SD525_ 59I|SD625_50I|
HD1080_60P
|HD1080_59P|HD1080_50P|
HD1080_60I|HD1080_59I|HD1 080_50I|
HD1080_30P|HD1080_30SF| HD10 80_29P|HD1080_29SF|
HD1080_25P|HD1080_25SF| HD10 80_24P|HD1080_24SF|
HD1800_23P|HD1080_23SF| HD72 0_60P|HD720_5994P|HD720_50P|
HD720_30P|HD720_2997P|HD7 20_25P| HD720_24P|HD720_2398P|
TKHD108
0_30P|TKHD1080_30SF| TKHD1080_2 9P|TKHD1080_29SF|
TKHD1080_25P|TKHD1080_25S F| TKHD1080_24P|TKHD1080_24SF|
TKHD1800_23P|TKHD1080_23S F
Sets the video standard (active image size, framing structure, and frame rate)
for the specified generator output. Valid arguments for this command depend
on the current output mode. The options are as follows:
SDxxx_xxI Standard Definition interlaced formats
HD1080_xxP
HD 1920 1080 progressive formats
HD1080_xxI
HD 1920 1080 interlaced formats
HD1080_xxSF formats HD 1920 1080 segmented frame
HD720_xxP
HD 1280 720 progressive formats
TK1080_xxP
“2K” 2048 1080 progressive formats
TK1080_xxSF “2K” 2048 1080 segmented frame formats
:OUTPut<1|2>:STANdard?
Returns the current video standard of specifi ed generator output.
:OUTPut<1|2>:SYNThesizer: SIGNal ZP_CIRCLE|ZP_DIAG|ZP_HSINE|
ZP_HSWEEP|ZP_VSINE|ZP_VSW EEP| ZP_1_CUSTOM|ZP_2_CUSTOM
Selects a zone plate test pattern for the specified generator output. The
options are as follows:
ZP_CIRCLE Circle Zone Plate
ZP_DIAG Diagonal Sine Zone Plate
ZP_HSINE Diagonal Sine Zone Plate
ZP_HSWEEP Horizontal Sine Zone Plate
ZP_VSINE Vertical Sine Zone Plate
ZP_VSWEEP Vertical S weep Zone Plate
Draft
164 TG8000 Multiformat Test Signal Generator Programmer Manual
