BG7 Black Generator module remote commands
:STATe <BOOLE
AN>
:STATe?
:SIGNal BB | BB_FREF | BB_10FID |
CB100PER | CB75 PER | CB_SMPTE
| FF40 PER | OTHER_ONE |
OTHER_TWO | BB_ NO_FREF |
CB100_OR | CB75 _OR
Command description
:OUTPut:CONFigure?
Returns the availability of color bars signal output option (Option CB). "1"
indicates that the option is available and "0" indicates the option is not
available.
:OUTPut<n>:STANdard
NTSC|NTSC_NSU|PAL|HD1080_ 60I|HD1080_59I|
HD1080_50I|HD1080_24SF|HD 1080_23SF|
HD1080_30P|HD1080_29P|HD1 080_25P|
HD1080_24P|HD1080_23P|HD7 20_60P|HD720_59P
| HD720_50P
Sets the video standard for a specific BLACK output. The choices are NTSC,
PAL, NTSC_NSU (NTSC no setup), and HD1080_60I to HD720_50P. The
<n> in the command represents the connector number. You can use any
connector number from 1 through 4.
:OUTPut<n>:STANdard
Returns the video standard for a specific BLACK output. The <n> in the
command represents the connector number. You can u
se any connector
number from 1 through 4 .
:OUTPut<n>:SIGNal BB|BB_FREF| BB_10FID|CB100PER|CB75PER|
CB_SMPTE|FF40PER|OTHER_ONE |OTHER_TWO|
BB_NO_FREF|CB100_OR|CB75_O R
Sets what kind of signal is available from a specific BLACK output. The <n>
in the command represents the connector number. You c an use any connector
number from 1 through 4 .
If the standard is NTSC or NTSC_NSU, the options are:
BB (black burst) or BB_FREF (black burst with field reference).
With Option CB you can also select:
BB_10FID (black burst with 10 field ID), CB100PER (100% color bars),
CB75PER (75% color bars), CB_SMPTE (SMPTE color bars), FF40PER
(40% flat field), OTHER_ONE (Other 1), or OTHER_TWO (Other 2).
If the standard is PAL, the options are:
BB (black burst) or BB_NO_FREF (black burst no field reference).
Draft
TG8000 Multiformat Test Signal Generator Programmer Manual 61
