Tektronix TG8000 Programmer's Manual

DVG7 Digital Video Generator module remote commands
:STATe
ON|OFF
:STANdard D2_NTSC | D1_NTS C | D1_PAL
:SIGNal BLACk | GRAY | FF50P |
WHITe
Command description
:OUTPut1:CIRCle:STATe ON|OFF
Turns the circle overlay on the video signal on or off. You can use 1 or
0 instead of ON or OFF.
:OUTPut1:CIRCle:STATe?
Returns the current circle overlay state.
:OUTPut1:CIRCle:DIAMeter <num eric_value>
Sets the diameter of the displayed circle. The unit is percent of active picture
height. You can set the diameter from 0% to 100% in 1% steps. You can also
use MIN, MAX, or DEF instead of a numeric value.
:OUTPut1:CIRCle:DIAMeter?
Returns the diameter of the displayed circle.
:OUTPut1:CIRCle:POSition:H ORizontal <numeric_value>
Sets the horizontal posit
ion of the circle as it appears on the active signal.
The unit is percent of active picture width. You can set the position from
-50% to +50% in 1% s teps. You can also use MIN, MAX, or DEF instead of
a numeric value.
:OUTPut1:CIRCle:POSition:H ORizontal?
Returns the current horizontal position of the circle as it appears on the active
signal.
:OUTPut1:CIRCle:POSition:V ERTical <numeric_value>
Sets the vertical posi
tion of the circle as it appears on the active signal. The
unit is percent of active picture height. You can set the position from -50%
to +50% in 1% steps. You can also use MIN, MAX, or DEF instead of a
numeric value.
:OUTPut1:CIRCle:POSition:V ERTical?
Returns the current vertical position of the circle as it appears on the active
signal.
:OUTPut<n>:EAUDio:CHANnel< m>:AMPLitude <numeric_value>
Draft
TG8000 Multiformat Test Signal Generator Programmer Manual 67
