GPS7 GPS Synchronization and Timecode module remote commands
:INPut:STAtus
:PCOUnter
Returns the program time.
:INPut:STAtus:SIG
Returns the GPS signal strength.
:INPut:STAtus:SAT
Returns two numbers characterizing the GPS satellite status. The numbers
are returned in the form "XX/XX". The first number represents the number
of satellites from which the receiver is getting good "fix" information; the
second number is the number of satellites that are in view (which may be
larger than the first number because the receiver may not be getting good fix
informat
ion from all the satellites).
:INPut:STAtus:ANTenna
Returns the antenna connection status. Connection status can be Power Off,
Open,Short,orNominal.
:INPut:STAtus:DIAG:STATus
Returns a s tring containing all GPS DIAG menu display items, separated by a
semicolon. The full list of returned values is:
Temperature
Oscillator Phase and DAC values
Oscillator lock state
Pow
er supply readings
+5V, +8V, -5V
Phase detect ramp value (these values are used for factory diagnostic analysis)
Up: A a nd B
Down: A and B
:INPut:STAtus:DIAG:GLOCK
Returns a string containing all Genlock DIAG menu display items, separated
by a semicolon. The full list of returned values is:
Stuck Bits - Status is indicated by "H" for high, "L" for low, and "-" for OK.
Shorted Bits - Status is indicated by "S" for shorted (always in pairs) and
"-" for OK.
Genlock Signal Amplitude min/max
Draft
TG8000 Multiformat Test Signal Generator Programmer Manual 79
