GPS7 GPS Synchronization and Timecode module remote commands
:INPut:STAtus
:GENlock
NOTE. This query is not supported by GPS7 modules that do not have a REF
IN connector.
Returns genlock reference status. The possible responses are INTernal,
ABSent, UNLocked, LOCKed, or NLOCK (near loss of lock).
:INPut:STAtus:GENlock:STA Tus
NOTE. This query is not supported by GPS7 modules that do not have a REF
IN connec
tor.
Returns a string containing amplitude and VITC information for the genlock
source. The VITC information is returned as Absent or as a line number. A
returned line number indicates the line on which the VITC information was
found.
:INPut:SOURce GPS |INTernal | NBURst| N318M|PBURst|HDSYnc
NOTE. The arguments NBURst, N318M, PBURst, and HDSYnc are not supported
by GPS
7 m odules that do not have a REF IN connector.
Sets the video reference source.
:INPut:SOURce
Returns the video reference source setting.
:INPut:LLOSs:ACTion
Sets the Loss of Lock action setting. The action can be set to switch to internal
or stay at current frequency when loss of lock occurs.
:INPut:LLOSs:ACTion
R
eturns the Loss Lock action setting.
:INPut:LLOSs:RECovery
Sets the Holdover Recovery action setting. The action can be set to Jam Phase,
Fast Slew, or Stay Legal. When a loss of lock occurs, this setting specifies
the method used to synchronize the time when lock is achieved. Recovery
methods are Jam Phase, Fast Slew, and Stay Legal (SMPTE specified).
:INPut:LLOSs:RECovery
Returns the Holdover Recovery action setting.
Draft
80 TG8000 Multiformat Test Signal Generator Programmer Manual
