Appendix A: Errors
CD14 Tester & CD AutoPlus Autosampler User Guide—75-108-800 Rev. B—31 May 2021 126 of 130
EAR99 technology subject to restrictions on cover page.
Appendix A: Errors
CD14 Tester Errors
CD14 Tester Errors
Error
Code
Error
Category
Error Message Title Fault Check the Following
2000 5
AutoMag X
communication error
1. Check mag connection.
2. Wrong probe config, check
system configuration.
2001 5 Vessel probe X missing
2002 5
Vessel probe X
configuration error
2003 5
Vessel probe X
communication error
The tester is unable to
communicate with
<probe number>.
1. Digital temperature probe
cable connection
2. Digital temperature probes
configuration
3. Digital temperature probes
connection to AutoMag board
4. Digital temperature probes
failure
5. Main board failure
2004 5
Vessel probe X
configuration mismatch
The method is trying to
use DTPs that are not
configured. Enable
DTPs in configuration.
1. The vessel temperature field
for method
2. System configuration of digital
temperature probes
2005 5
Vessel probe X offset
out of range
User tried to apply an
offset greater than 9.99
or less than -9.99.
1. Probe offset is entered
correctly
2. Temperature probe failure
2006 5
External temperature
probe (2) failure
Heater cannot
communicate with
external temperature
probe.
1. External probe connection
2. External probe failure
3. Heater board failure
2007 5
Vessel probe X
unknown calibration
2008 5
X spindle board com
error
The tester can't
communicate with the
spindle board
1. Check the connection
2. Spindle board failure
3. Main board failure
2009 5
Magazine X homing
error
mcode=1, homing
distance too long.
1. Home it again. Make sure
motor is moving
2. Check lead screw and
magazine coupling.
3. Spindle control board failure
2010 5
Magazine X thermal
warning
mcode=4, Magazine
motor driver report too
hot.
1. Move it again. Make sure
motor is moving
2. Check lead screw and
magazine coupling
3. Spindle control board failure
2011 5
Magazine X thermal
shutdown
mcode=8, Magazine
motor driver report too
hot.
1. Move it again. Make sure
motor is moving.
2. Check lead screw and
magazine coupling
3. Spindle control board failure
