Appendix A: Errors
CD14 Tester & CD AutoPlus Autosampler User Guide—75-108-800 Rev. B—31 May 2021 127 of 130
EAR99 technology subject to restrictions on cover page.

CD14 Tester Errors
Error
Code
Error
Category
Error Message Title Fault Check the Following
2012 5
Magazine X over
current error
mcode=16, Magazine
motor driver report
overcurrent.
1. Move it again. Make sure
motor is moving.
2. Check lead screw and
magazine coupling
3. Spindle control board failure
2013 5
Magazine X driver lost
steps on winding 1
mcode=32, Magazine
motor driver report
overcurrent.
1. Move it again. Make sure
motor is moving.
2. Check lead screw and
magazine coupling
3. Spindle control board failure
2014 5
Magazine X driver lost
steps on winding 2
mcode=64, Magazine
motor driver report
overcurrent.
1. Move it again. Make sure
motor is moving.
2. Check lead screw and
magazine coupling
3. Spindle control board failure
2015 5
Magazine X encoder
missing steps
mcode=128, Magazine
encoder and driver
mismatch.
1. Move it again. Make sure
motor is moving.
2. Check lead screw and
magazine coupling
3. Spindle control board failure
2016 5
Magazine X calibration
error
mcode=2, Calibration
error.
1. Move it again. Make sure
motor is moving.
2. Check lead screw and
magazine coupling
3. Spindle control board failure
2017 5
Spindle X spindle board
com recovery
The tester had
communication problem
with the spindle board
1. Check the connection
2. Spindle board failure
3. Main board failure
2018 5
Spindle X commute
error
ecode=1, Spindle motor
commutation error.
1. Run it again make sure motor
is moving
2. Check spindle motor
connection
3. Spindle control board failure
2019 5
Spindle X Hall1 sensor
error
ecode=2, Spindle motor
sensor 1 missing.
1. Check spindle belt tension.
2. Check spindle motor
connection.
3. Spindle control board failure
2020 5 Spindle X sensor error
ecode=4, Spindle motor
sensor 2 missing.
1. Check spindle belt tension.
2. Check spindle motor
connection.
3. Spindle control board failure
2021 5 Spindle X sensor error
mcode=8, Spindle
motor sensor 3 missing.
1. Check spindle belt tension.
2. Check spindle motor
connection.
3. Spindle control board failure
2022 5 Spindle X stall error
mcode=0x40, Spindle
motor driver
overcurrent.
1. Check spindle belt tension.
2. Check spindle motor
connection.
3. Spindle control board failure
2023 5
Spindle X driver
overheat error
mcode=0x80, Spindle
motor driver overheat.
1. Check spindle belt tension.
2. Check spindle motor
connection.
3. Spindle control board failure
