CD14 Tester Errors
Error
Code
Error
Category
Error Message Title Fault Check the Following
2024 5
Spindle X board
configuration initialize
error
mcode=0x100,
configuration
initialization.
1. First time power up
2. I2C problem
3. Spindle control board failure
2025 5
Spindle X board
EEPROM error
mcode=0x200,
configuration
initialization.
1. I2C problem
2. Spindle control board failure
2026 5
Spindle X board serial
command overflow
mcode=0x400, serial
port overflow.
1. RS232 problem
2. Spindle control board failure
2027 5
Spindle X board task
overflow error
mcode=0x800, task
overflow.
1. Internal problem
2. Spindle control board failure
2028 5
AutoMag X
communication
recovery
2029 5
AutoMag X return home
check error
2500 5
Heater communication
error
The tester and heater
are not communicating.
1. Heater power
2. Heater connection
2501 5
Heater probe 1 failure
(control probe)
ecode=1, Heater cannot
communicate with Inlet
temperature probe.
1. Inlet probe connection
2. Inlet probe failure
3. Heater board failure
2502 5
Heater input power
(mains) error
ecode=0x80, heater
failure
1. Emergency thermo-switch has
tripped breaking the connection
between the heater and power
source.
2. Heater coil connection
3. Heater coil failure
4. Heater board failure
2503 5
Heater thermistor
sensor failure
ecode=4, Heater cannot
communicate with
safety probe.
1. Safety probe connection
2. Safety probe failure or no
water flow in heater
3. Heater board failure
2504 5
Heater watchdog timer
reset
ecode=0x40, did not
receive command for 15
seconds
1. Check connection to main
control board.
2. Check main control board.
3. Heater board failure
2505 5
Heater configuration
memory failure
mcode=0x100,
configuration
initialization.
1. First time power up
2. I2C problem
3. Heater board failure
2506 5 Heater fan failure ecode=8, fan failure
1. Check fan connection.
2. Fan failure
3. Heater board failure
2507 5 Heater pump failure ecode=0x20, fan failure
1. Check pump connection
2. Pump failure
3. Heater board failure
2508 5
Heater board I2C bus
failure
mcode=0x200,
configuration
initialization.
1. I2C problem
2. Heater board failure
2509 5
Heater board serial port
overflow
mcode=0x400, serial
port overflow.
1. RS232 problem
2. Heater board failure
2510 5
Heater board
background task
overrun
mcode=0x800, task
overflow.
1. Internal problem
2. Heater board failure
