User Guide
36
LACP Parameters—Config
To config LACP parameters
Click Port Management -> Link Aggregation -> LACP Protocol and below screen will be displayed:
Fields on the screen are described below:
Config system priority (0-65535). The default is
32768.
Displays Enable when corresponding port joins
a LACP aggregation group and Disable when
the port does not join any LACP aggregation
group or joined a static aggregation group.
Config port priority (0-65535). The default is
32768.
Select a LACP timeout: long or short. The
default is long.
Displays the LACP aggregation group ID.
To config LACP parameters on a single port: click the corresponding port as seen below:
