Tenda V300 User Manual

50
 IPv6 address can only be Aggregate Global Unicast Address and Unique Local Address. Link-Local
Unicast Addresses and Multicast Addresses are not permitted.
 The IPv6 address must be entered with a prefix length.
Parameter
Description
Enable DHCPv6 Server
Check to enable the DHCPv6 Server.
Stateless
If selected, IPv6 clients will generate IPv6 addresses automatically based on the Prefix
Delegation's IPv6 prefix and their own MAC addresses.
Stateful
Stateful DHCPv6 is supported based on the assumption of prefix length less than 64.
Select this option and configure the start/end interface ID and leased time. The router
will automatically assign IPv6 addresses to IPv6 clients.
Start interface ID/End
interface ID
Specify the start/end interface ID Interface ID does NOT support ZERO COMPRESSION
"::". Please enter the complete information. For example: Please enter "0:0:0:2"
instead of "::2".
Leased Time (hour)
The lease time is a time length that the IP address is assigned to each device before it
is refreshed.
Enable RADVD
The RADVD (Router Advertisement Daemon) implements link-local advertisements of
IPv6 router addresses and IPv6 routing prefixes using the Neighbor Discovery Protocol
(NDP) and is used by system administrators in stateless auto configuration methods of
network hosts on Internet Protocol version 6 networks. Check the checkbox to enable
the RADVD.
Enable ULA Prefix
Advertisement
If enabled, the router will advertise ULA prefix periodically.
Randomly Generate
If selected, address prefix can be automatically generated.
Statically Configure
If you select this option, you need to manually configure the address prefix and life

Tenda V300 Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Cables included	LAN (RJ-45), Phone (RJ-11)
Certification	CE, FCC, RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	64-bit WEP, 128-bit WEP, SNMP, SSID, WDS, WPA-PSK, WPA2-PSK, WPS
Supported network protocols	G.994, ANSI T1.413 2, ITU-T G.992.1 (G.dmt), ITU-T G.992.2 (G.lite), ITU-T G.992.3 (G.dmt.bis) Annex A/L/M, ITU-T G.992.5 Annex A, G.993.2 (VDSL2), G.993.5, G.993.2 Amd 7 (ToD), G.998.4 (G.inp), ATM, PTM
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11n)	20 dBmW
RJ-11 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
Output current	1 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Product type	Tabletop router
Product color	White
LED indicators	DSL, LAN, Power, USB, WAN, WLAN, WPS
Antenna gain level (max)	5 dBi

Weight and Dimensions

Depth	105.2 mm
Width	157.8 mm
Height	29.4 mm
