Tenda V300 User Manual

52
Parameter
Description
Use Interface
Select a WAN connection to which you wish to apply the rules. When there is only one
WAN connection available, the rules will be automatically applied to it.
Service Name
Select a Service: Allows you to select an existing service from the drop-down list.
Custom Service: Allows you to customize a service.
Server IP Address
Enter the IP address of your local computer that will provide this service.
External Port Start and
External Port End
These are the start number and end number for the public ports at the internet
interface.
Protocol
Select a protocol from the Protocol drop-down list. If you are unsure, select TCP/UDP.
Internal Port Start and
Internal Port End
These are the start number and end number for the ports of a computer on the
router’s local area network (LAN).
Application Example
You have set up an FTP server on your LAN:
- An FTP server (using the default port number of 21) at the IP address of 192.168.1.100
And want your friends to access the FTP server and web server on default port over the internet. To access your
FTP or web server from the Internet, a remote user has to know the Internet IP address or internet name of the
modem router, such as www.tendacn.com. In this example, we assume the internet IP address of your router is
183.37.227.201. Then follow instructions below:
To configure the router to make your local FTP server public:
Choose Advanced > Advanced Setup > NAT > Virtual Server to enter the configuration page.

Tenda V300 Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Cables included	LAN (RJ-45), Phone (RJ-11)
Certification	CE, FCC, RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	64-bit WEP, 128-bit WEP, SNMP, SSID, WDS, WPA-PSK, WPA2-PSK, WPS
Supported network protocols	G.994, ANSI T1.413 2, ITU-T G.992.1 (G.dmt), ITU-T G.992.2 (G.lite), ITU-T G.992.3 (G.dmt.bis) Annex A/L/M, ITU-T G.992.5 Annex A, G.993.2 (VDSL2), G.993.5, G.993.2 Amd 7 (ToD), G.998.4 (G.inp), ATM, PTM
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11n)	20 dBmW
RJ-11 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
Output current	1 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Product type	Tabletop router
Product color	White
LED indicators	DSL, LAN, Power, USB, WAN, WLAN, WPS
Antenna gain level (max)	5 dBi

Weight and Dimensions

Depth	105.2 mm
Width	157.8 mm
Height	29.4 mm
