Terex Genie GS84D-401 User Manual

Service and Repair Manual June 2021
Repair Procedures
94 GS
™
-84 • GS
™
-90 Part No. 1306587GT
7-10
Generator Relief Valve Manifold Components
The generator relief valve manifold is located in the hydraulic manifold compartment.
Index
No.
Description
Schematic
Item
Function
Torque
1
Relief valve, 350
0 psi / 241 bar AR
Generator pressure circuit
25 ft-lbs / 34
Nm
Note: 'alpha' callouts refer to corresponding notes on the hydraulic schematic.
